Triton 2450万像素千兆以太网工业相机

传感器型号
Sony IMX540 CMOS
分辨率
24.5 MP, 5320 x 4600 px
帧率
4.5 FPS
Model SKUs 黑白/彩色 镜头接口 GigE Vision 连接器 随附配件
TRI245S-CC 彩色 C-mount M12 M8 GPIO IP67 塞子
TRI245S-MC 黑白 C-mount M12 M8 GPIO IP67 塞子

请选择您的相机变量:

订货型号: N/A 分类: ,

规格

传感器特性
名称 Sony IMX540 CMOS
快门 Global
靶面尺寸 19.3mm (Type 4/3)
分辨率 5320 x 4600 px, 24.5 MP
像元尺寸 2.74 µm (H) x 2.74 µm (V)
帧率* 4.5 FPS (4.9 FPS) @ 24.5 MP
物理特性
尺寸 29 x 29 x 45 mm
镜头接口 C-Mount
重量 67 g
接口和电源信息
数据接口 1000BASE-T GigE M12, PoE
数字I/O 8 pin M8 connector
路光耦隔离I/O 1 input, 1 output
路双向可配置非隔离I/O 2 bi-directional
功率要求 PoE (IEEE 802.3af), or 12-24 VDC external
功耗 3.5W via PoE, 3W when powered externally
*最大帧率基于10%的 “设备链路吞吐量储备”,用于重新发送数据包。括号()中的FPS是基于0%的 “设备链路吞吐量储备”。LUCID建议为数据流可靠性保留10%。
成像特性
缓存容量 128 MB
Image Processing Gain, gamma, black level, white balance, LUT, CCM, pixel correction, hue, saturation, color space conversion
数据格式 Mono8/10/12/16, Bayer8/10/12/16, RGB8, YUV422, YUV411
Image Modes Horizontal and vertical binning, decimation, ROI, horizontal and vertical flip
ADC 12 bit
增益范围 0 dB to 48 dB analog and digital
曝光时间范围 45 μs to 10 s (正常模式) / 1 μs to 2.7 μs (快速模式)
相机功能
User Sets 1 default and 2 custom user set
File System Size 16 MB
Chunk Data Timestamp, frame counter, offset X/Y, width/height, exposure time, gain, black level, line status, sequencer set
Event Data Acquisition start/end, exposure start/end, line rise/fall, error
Counter & Timer 2 counters and 2 timers
Sequencer Exposure time, gain
Synchronization Software trigger, hardware trigger, PTP (IEEE 1588)
标准和认证
兼容 GigE Vision v2.0
认证 CE, FCC, RoHS, REACH, WEEE
存储温度 -30 to 60°C
工作温度 -20 to 55°C
湿度 Operating: 20% ~ 80%, relative, non-condensing
冲击和振动标准 DIN EN 60068-2-27, DIN EN 60068-2-64
保修 3 year

EMVA 1288 数据

交互式图表-请将鼠标悬停在图中的点上以显示量子效率%

TRI245S-M (黑白, Sony IMX541 CMOS)
黑白EVMA 1288结果
动态范围 70.41 dB
SNR (最大值) 39.67 dB
饱和容量 9272 e-
绝对灵敏度阈值 (测量在527.5nm) 3.85 γ
颞暗噪声 2.19 e-
增益 0.42 DN / e-
暗电流 2.03 e- / s
暗信号非均匀性 1.9 e-
光响应非均匀性 0.72 %
线性误差 (高/低) 0.11/-0.24 %
TRI245S-C (彩色, Sony IMX541 CMOS)
彩色EVMA 1288结果
动态范围 70.39 dB
SNR (最大值) 39.71 dB
饱和容量 9369 e-
绝对灵敏度阈值 (测量在527.5nm) 5.12 γ
颞暗噪声 2.23 e-
增益 0.42 DN / e-
暗电流 3.93 e- / s
暗信号非均匀性 2.23 e-
光响应非均匀性 0.81 %
线性误差 (高/低) 0.10/-0.18 %

emva-1288-logo

EMVA 1288是机器视觉传感器和相机规格测量和展示标准。 有关EMVA 1288标准的更多信息,请访问http://www.emva.org/standards-technology/emva-1288/

图纸

Triton C-Mount 图纸
Triton c-mount 图纸
